產品展示當前位置：首頁 > 產品展示Higher voltage rating provides overall system efficiency using smaller, more economical conductors while meeting the needs of higher voltage. Up to ten times faster opening under high fault current conditions helps assure reliable protection of circuits and components. Greater ampacity within sizing guidelines, Excellent power of resisting voltaic impingement and environment temperature tolerance, Excellent resistance to mechanical vibration and impact resistance.
| Connect | Part No. | Fuse Amps | Size | Average @250KA/1500Vdc | Power Loss (W) | Approvals | ||
| A2s Melting | A2t Clearing | 100% |
|
|
||||
| Flush-end contact | GFEVT1500-100A-74E | 100A | 3# | 1,121 | 4,535 | 60 | ● | ● |
| GFEVT1500-125A-74E | 125A | 3# | 1,706 | 8,091 | 68 | ● | ● | |
| GFEVT1500-160A-74E | 160A | 3# | 3,705 | 13,566 | 90 | ● | ● | |
| GFEVT1500-200A-74E | 200A | 3# | 5,070 | 22,772 | 110 | ● | ● | |
| GFEVT1500-250A-74E | 250A | 3# | 10,140 | 43,605 | 120 | ● | ● | |
| GFEVT1500-315A-74E | 315A | 3# | 20,604 | 73,644 | 136 | ● | ● | |
| GFEVT1500-350A-74E | 350A | 3# | 28,309 | 100,441 | 148 | ● | ● | |
| GFEVT1500-400A-74E | 400A | 3# | 37,320 | 130,559 | 171 | ● | ● | |
| GFEVT1500-450A-74E | 450A | 3# | 52,570 | 186,198 | 187 | ● | ● | |
| GFEVT1500-500A-74E | 500A | 3# | 71,128 | 250,479 | 204 | ● | ● | |
| GFEVT1500-550A-74E | 550A | 3# | 89,014 | 306,195 | 221 | ● | ● | |
| GFEVT1500-630A-74E | 630A | 3# | 125,840 | 422,594 | 248 | ● | ● | |
| GFEVT1500-700A-74E | 700A | 3# | 174,518 | 573,595 | 273 | ● | ● | |
| GFEVT1500-800A-74E | 800A | 3# | 271,019 | 863,105 | 294 | ● | ● | |
| GFEVT1500-900A-74E | 900A | 3# | 389,563 | 1,192,378 | 305 | ○ | ○ | |
| GFEVT1500-1000A-74E | 1000A | 3# | 523,585 | 1,549,528 | 362 | ○ | ○ | |
| *GFEVT1500-1100A-74E | * 1100A | 3# | 719,385 | 2,056,080 | 385 | ○ | ○ | |
| * GFEVT1500-1200A-74E | * 1200A | 3# | 973,208 | 2,682,900 | 391 | ○ | ○ | |
